VM Audio Encore 12-Inch High Excursion Subwoofer | ECW120

VM-ECW120VM Audio Encore 12-Inch High Excursion Subwoofer | ECW120
VM-ECW120VM Audio Encore 12-Inch High Excursion Subwoofer | ECW120VM-ECW120VM Audio Encore 12-Inch High Excursion Subwoofer | ECW120VM-ECW120VM Audio Encore 12-Inch High Excursion Subwoofer | ECW120VM-ECW120VM Audio Encore 12-Inch High Excursion Subwoofer | ECW120
Your Price
$126.95
Shipping
Free Standard ShippingSee details
Availability
In Stock
Want it fast? Enter your zip code to get your delivery date.
SKU
VM-ECW120
Condition
New
Styles
Size

Customer Ratings

4 Stars. 1 review. Write your own review.

DescriptionFeatures

Encore 12" 3000W
High Excursion Subwoofer
MSRP: $399.95

Some people spend years developing an ear for pure sound. Only the clearest and finely-tuned audio experience will satisfy them.

The VM Audio Encore 12" high excursion subwoofer was designed by our professional team of engineers for exactly this type of consumer.

Features like the linear-flex spider ensure the clarity of the low frequency notes while the dynamic high-magnitude cone increases the precision of this incredible subwoofer.

Every aspect of the Encore series 12" subwoofer was built to preserve the integrity of the low frequencies in your music while still giving you the power you want to crank up the volume.



WHAT YOU NEED TO KNOW


The Power You Need

The ECW120 pumps 1500 watts of RMS power and peak power of 3000 watts. Whether you're enjoying a symphony orchestra or something a little more bass-heavy, the ECW120 delivers the right amount of power for any listening preferences.


Purity of Sound

With sound enthusiasts, purity is everything. The Encore series 12" subwoofers uses advanced lateral mechanical suspension, a high-excursion wide surround and a deep piston cone diaphragm to maintain the absolute highest low frequency purity.


Built to Last

The elements can impact more than just the outside of your car. The Encore series 12" subwoofer features a wide rubber surround and nickel-plated wire connection terminals to protect from oxidation.


Voice Coil Size

Our Encore series 12" subwoofers can push a lot of power and we use 3" (76.5mm) voice coils made from the highest quality materials in order to handle that kind of power. Ferrofluid coating, direct air contact and large magnet surface area all work to dissipate the heat, protect the coils and maintain the performance of the sub.


Die-Cast Basket

The structural integrity of your subwoofers is crucial which is why the Encore series 12" sub has a die-cast and rust-treated stamped steel basket to eliminate any buzzing and to protect it against moisture.


Large Magnet Structure

For the Encore series 12" subwoofer, our engineers use large, high-quality magnets for several reasons. First, it allows for more excursion and power. Second, it also provides more surface area to increase the speed of cooling for the subwoofer's components.
HIGHLIGHTS

RMS Power: 1500 Watts
Peak Power: 3000 Watts
Dual Voice Coil Low Frequency Transducers
Lateral High Thrust Mechanical Suspension System
Relentless High Excursion Wide Surround
Multi-Roll, Linear-Flex Damping Control Large Spider
Low Molecular, Deep Piston Cone Diaphragm
Ultra Deep, Proprietary Rust-Treated Stamp Steel Basket
High Impact-Resistant One Piece Magnet Boot Protection
Aerodynamic, Direct Voice Coil Surface-Cooling System
Extended, Thermal Cooling Vented Pole Piece Motor Structure
Heavy-Duty Nickel Plated Wire Connection Push Terminals
Spider Woven High-Conducting Silver Tinsel Leads
Mounting-Guiding Tall Beveled Color Matching Trim Ring
Sealed or Ported Enclosure Performance
Single 2ohm/8ohm or Dual 4ohm Impedance Configurations

PROFESSIONAL PHONE SUPPORT

Hours – Monday-Friday 9 AM-5 PM CST | T – 855-283-4699

TECHNICAL SPECIFICATIONS
Size:
12"
Nominal Impedance:
Dual 4 Ohm
RMS Power:
1500W
Peak Power Handling:
3000W
Voice Coil Diameter:
3" (76.5mm)
Magnet Weight:
75oz * 2
Frequency Response:
23Hz - 340Hz
Clone Material:
Polypropylene
Surround Material:
Butyl Rubber
Mounting Diameter:
11.14" (283mm)
Mounting Height:
8.19" (208mm)
Warranty:
1 Year

IDEAL ENCLOSURE DETAILS


PARAMETERS
Free Air Resonance (Fs):
38 Hz
Driver Compliance (Cms):
0.09 mm/N
Moving Mass (Mms):
181 g
Driver Total Q (Qts):
0.47
Electrical Q (Qes):
0.53
Mechanical Q (Qms):
4.3
Equivalent Stiffness (Vas):
29.7 Ltr
Effective Cone Area (Sd):
176 sq.cm
Inductance 1kHz (Le):
2.3 mh
Motor Force (BL):
23.3 T-M
Efficiency (no):
0.19%
Sensitivity (SPL @1W/1m):
93 dB
D.C. Coil Resistance (Re):
7.2 ohm ea.





INNOVATIONS
AND TECHNOLOGIES

Lateral Thrust Suspension
Dynamic high-magnitude moving diaphragm provides state-of-the-art enhanced motion control for precise sound that lives up to the highest standards. Also, lateral movements can cause the voice coil and pole to touch and our lateral thrust suspension system prevents that kind of damage from occurring.
LMDP Diaphragm
Innovative deep pressurizing piston cone dominates the soundscape by boosting low frequency notes to make a powerful impression on listeners. With a low-molecular design, this cone diaphragm is lighter and more responsive for quicker bass response and purity of sound.
Surface-Cooling
Thermal failure is something that every audiophile takes extreme measures to prevent. With the Encore series 12" subwoofer, our engineers use groundbreaking new voice coil technology as well as a vented pole piece to quickly dissipate heat by receiving a direct airflow for smooth and pure sound regardless of temperature.


IN THE BOX


-Encore 12" Subwoofer


-User Guide
